Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Método de control:Manual

Carrete:1 carrete

Flujo Nominal:40 l/min (10,5 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G1/2

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P40 Válvula Direccional Monobloque

Tamaño del embalaje:23*16*11

Peso bruto:3.00 kg

Disponibilidad: En stock

1026 personas están viendo este producto

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT

Your Hydraulic Partner: OEM, ODM, and White Label Services for P40-G12-1OT drawing image

Introducing Your Hydraulic Partner: a leading provider of OEM, ODM, and White Label services for hydraulic products. Our expertise lies in developing and manufacturing high-quality hydraulic components and systems tailored to meet your specific needs. Partner with us to elevate your product offerings with our exceptional manufacturing capabilities and commitment to innovation.

Serie P40 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 250 bar (3600 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Puerto de Salida G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamaño de Puerto G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

Our P40-G12-1OT monoblock valve is a prime example of our engineering prowess. Designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles, this valve delivers exceptional performance with a rated flow of 40 L/min, a maximum pressure of 250 bar, and an operating viscosity range of 15 - 75 mm²/s. Its robust construction ensures reliable operation in harsh environments with an ambient temperature range of -40°C to +80°C. Whether you require OEM manufacturing, ODM customization, or White Label branding, we have the expertise and infrastructure to fulfill your requirements. Our commitment to quality and customer satisfaction sets us apart, making us the ideal choice for businesses seeking a reliable hydraulic partner.
