SD5 Manual Directional Valve: Manufacturer, Supplier, and Wholesaler

Método de control:Manual

Carrete:7 carretes

Flujo Nominal:45 l/min (11,8 gal EE. UU./min)

Presión Máxima:315 bar (4600 psi)

Puerto de Entrada:G3/8

Puerto de Salida:G3/8

Tamaño de Puerto:G3/8

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie SD5 Válvula Direccional Monobloque

Tamaño del embalaje:23*36*13

Peso bruto:15.30 kg

Disponibilidad: En stock

1035 personas están viendo este producto

SD5 Manual Directional Valve: Manufacturer, Supplier, and Wholesaler

SD5 Manual Directional Valve: Manufacturer, Supplier, and Wholesaler

SD5 Manual Directional Valve: Manufacturer, Supplier, and Wholesaler drawing image

The SD5 Series Hydraulic Valve is a 7-section manual directional valve designed for heavy-duty applications in material handling, construction, agriculture, and industrial vehicles. This robust monoblock valve offers a rated flow of 40 L/min and a maximum pressure of 305 bar, making it suitable for a wide range of equipment.

Serie SD5 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +60 °C (-40 °F a +140 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 305 bar (4400 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8, G1-1/2
Puerto de Salida G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8
Tamaño de Puerto G3/8, G1/2, M18×1.5, M20×1.5, SAE 6, SAE 8

The Hig Tech SD5 Manual Directional Valve is a high-performance hydraulic valve engineered for demanding applications. Its 7-section design provides precise control over hydraulic circuits, while the monoblock structure ensures durability and reliability. With a rated flow of 40 L/min and a maximum pressure of 305 bar, this valve is ideal for powering telehandlers, forklifts, stackers, aerial platforms, mini-excavators, compact wheel loaders, harvesters, bale wrappers, seeding machines, and wood splitters. The valve operates smoothly across a wide viscosity range and can withstand temperatures from -40°C to +60°C. Its manual control system offers easy and intuitive operation, making it a versatile choice for a variety of hydraulic applications.
