P40-S Hydraulic Directional Control Valve - Reliable & Durable

Método de control:Solenoide

Carrete:4 carretes

Flujo Nominal:40 l/min (10,5 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G1/2

Tamaño de Puerto:G3/8

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P40 Válvula Direccional Monobloque

Tamaño del embalaje:35*23*15

Peso bruto:12.70 kg

Disponibilidad: En stock

481 personas están viendo este producto

P40-S Hydraulic Directional Control Valve - Reliable & Durable

P40-S Hydraulic Directional Control Valve - Reliable & Durable

P40-S Hydraulic Directional Control Valve - Reliable & Durable drawing image

The P40-S Hydraulic Directional Control Valve is a reliable and durable 4-section monoblock valve with a 40 L/min rated flow and 250 bar max pressure. Ideal for material handling, construction, agriculture, and industrial vehicles.

Serie P40 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 250 bar (3600 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Puerto de Salida G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamaño de Puerto G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

We are a global hydraulic product manufacturer offering manufacturing, OEM, private labeling, customization, and wholesale services. We are seeking distributors, wholesalers, agents, and trading companies. Our flagship product, the **P40-S Hydraulic Directional Control Valve**, is a high-performance, reliable and durable solution for various applications. This **4-section monoblock valve** features solenoid control, a rated flow of 40 L/min (10.5 US gpm), and a maximum pressure of 250 bar (3600 psi). Its **robust construction** and wide operating temperature range (-40°C to +80°C) ensure reliable performance in demanding environments. Key features include:

* **Solenoid Control:** Precise and efficient operation.
* **4-Section Design:** Versatile control for complex hydraulic systems.
* **Monoblock Structure:** Compact design and enhanced durability.
* **High Flow Rate (40 L/min):** Efficient operation for demanding applications.
* **High Pressure Rating (250 bar):** Suitable for heavy-duty equipment.
* **Wide Viscosity and Temperature Range:** Adaptable to various operating conditions.
* **Applications:** Material handling (forklifts, telehandlers), construction and earthmoving (mini-excavators, skid steer loaders), agriculture (tractors, harvesters), and industrial vehicles.

As a **manufacturer and factory supplier**, we offer competitive pricing and flexible solutions to meet your needs. We provide **factory wholesale** options and welcome inquiries for **OEM, private labeling, and custom designs**. We are actively seeking partnerships with **distributors, wholesalers, agents, and trading companies** worldwide. Contact us today to explore collaboration opportunities and get a quote. Our **P40 Series hydraulic valve** is your reliable choice for various applications. Don't hesitate to contact us to discuss your specific requirements and benefit from our **factory direct pricing** and exceptional quality.
