P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

Método de control:Manual

Carrete:1 carrete

Flujo Nominal:40 l/min (10,5 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G1/2

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P40 Válvula Direccional Monobloque

Tamaño del embalaje:23*16*11

Peso bruto:3.00 kg

Disponibilidad: En stock

1183 personas están viendo este producto

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier

P40-G12-1OT Hydraulic Directional Valve | Manufacturer & Global Supplier drawing image

The Lkf Flow Valve P40-G12-1OT is a high-performance hydraulic directional valve designed for use in a wide range of applications, including construction equipment, material handling, industrial vehicles, and agriculture. This manual control monoblock valve features a rated flow of 40 L/min and a maximum pressure of 250 bar, making it suitable for demanding applications. It is also compatible with a variety of equipment, including telehandlers, forklifts, all-terrain cranes, and more.

Serie P40 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 250 bar (3600 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Puerto de Salida G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamaño de Puerto G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The Lkf Flow Valve P40-G12-1OT is a reliable and durable hydraulic directional valve designed for heavy-duty applications. It features a robust monoblock construction and a single spool, providing a compact and efficient design. The valve is equipped with a manual control system for easy operation and offers a rated flow of 40 L/min (10.5 US gpm) with a maximum pressure of 250 bar (3600 psi). It is suitable for operating viscosities ranging from 15 to 75 mm²/s (15 cSt to 75 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). The valve is specifically designed for use in construction equipment, material handling, industrial vehicles, and agriculture. It is compatible with a wide range of applications and equipment models, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. This versatile and reliable hydraulic valve offers superior performance and durability, making it an ideal choice for a wide range of demanding applications.
