Monoblock Directional Valve Private Label & OEM Services | P80 Series

Método de control:Manual

Carrete:1 carrete

Flujo Nominal:80 l/min (21,2 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G3/4

Puerto de Salida:G3/4

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P80 Válvula Direccional Monobloque

Tamaño del embalaje:26*15*11

Peso bruto:5.00 kg

Disponibilidad: En stock

1142 personas están viendo este producto

Monoblock Directional Valve Private Label & OEM Services | P80 Series

Monoblock Directional Valve Private Label & OEM Services | P80 Series

Monoblock Directional Valve Private Label & OEM Services | P80 Series drawing image

The P80 Series Electrical Distributor Monoblock Directional Valve is a robust and reliable hydraulic component designed for a wide range of applications in material handling, construction, agriculture, and industrial vehicles. It offers manual control, 1 section, and a rated flow of 80 L/min. We provide OEM and private label services to meet your specific needs.

Serie P80 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Manual y joystick
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 80 l/min (21,2 gal EE. UU./min)
Presión Máxima 315 bar (4600 psi)
Puerto de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Puerto de Salida G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamaño de Puerto G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80 Series Electrical Distributor Monoblock Directional Valve is a high-performance hydraulic valve that delivers exceptional reliability and durability. It features manual control for easy operation and is built with a robust monoblock structure. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for demanding applications in various industries. This valve is designed for use in telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. We offer OEM and private label services, allowing you to customize the valve to your specific requirements. Whether you need a branded product or a custom-designed solution, our team can help you develop a valve that meets your exact needs. We are committed to providing high-quality products and exceptional customer service.
