Monoblock Directional Valve P40-G12-OT | Wholesale & OEM

Método de control:Manual

Carrete:3 carretes

Flujo Nominal:40 l/min (10,5 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G1/2

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P40 Válvula Direccional Monobloque

Tamaño del embalaje:24*21*13

Peso bruto:6.60 kg

Disponibilidad: En stock

1150 personas están viendo este producto

Monoblock Directional Valve P40-G12-OT | Wholesale & OEM

Monoblock Directional Valve P40-G12-OT | Wholesale & OEM

Monoblock Directional Valve P40-G12-OT | Wholesale & OEM drawing image

This P40 Series 3-section monoblock directional valve is a compact and powerful hydraulic valve designed for mini excavators and other construction equipment. It features a manual control method, a rated flow of 40 L/min, and a maximum pressure of 250 bar.

Serie P40 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 250 bar (3600 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Puerto de Salida G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamaño de Puerto G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

This P40-G12-OT mini excavator monoblock directional valve is a high-performance hydraulic component for a variety of applications. It offers a 3-section design with a manual control method, making it easy to operate. The valve boasts a rated flow of 40 L/min and can withstand a maximum pressure of 250 bar. Its operating viscosity range is 15 - 75 mm²/s, and it can withstand ambient temperatures from -40°C to +80°C. This versatile valve is suitable for a wide range of applications in material handling, construction and earth moving, agriculture, and industrial vehicles. Some common applications include telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders.
