Manual 6 Spool Monoblock Directional Valve Exporter

Método de control:Manual

Carrete:6 carretes

Flujo Nominal:80 l/min (21,2 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G3/4

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P80 Válvula Direccional Monobloque

Tamaño del embalaje:26*36*11

Peso bruto:18.60 kg

Disponibilidad: En stock

1300 personas están viendo este producto

Manual 6 Spool Monoblock Directional Valve Exporter

Manual 6 Spool Monoblock Directional Valve Exporter

Manual 6 Spool Monoblock Directional Valve Exporter drawing image

This is a high-quality manual 6 spool monoblock directional hydraulic valve for excavators, designed for reliable operation in construction, material handling, and industrial applications. It features a robust design, high flow rate, and a wide operating temperature range, making it suitable for a variety of heavy equipment.

Serie P80 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Manual y joystick
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 80 l/min (21,2 gal EE. UU./min)
Presión Máxima 315 bar (4600 psi)
Puerto de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Puerto de Salida G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamaño de Puerto G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

This P80 series manual 6 spool monoblock directional hydraulic valve is a powerful and versatile control solution for excavators and other heavy equipment. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), it offers exceptional performance in demanding applications. Its robust design and wide operating temperature range (-40°C to +80°C) ensure reliable operation in various environments. The valve is ideal for a variety of applications including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. We offer this valve in various configurations to meet your specific requirements, including OEM, ODM, and custom designs. We are a leading manufacturer and exporter of hydraulic valves, providing high-quality products and competitive pricing. Contact us today to learn more about our products and services.
