Hydraulic Valves P40-U34-2OT | Factory Direct & Global Distribution

Método de control:Manual

Carrete:2 carretes

Flujo Nominal:40 l/min (10,5 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:SAE 8

Puerto de Salida:SAE 8

Tamaño de Puerto:SAE 8

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P40 Válvula Direccional Monobloque

Tamaño del embalaje:23*18*13

Peso bruto:4.80 kg

Disponibilidad: En stock

1061 personas están viendo este producto

Hydraulic Valves P40-U34-2OT | Factory Direct & Global Distribution

Hydraulic Valves P40-U34-2OT | Factory Direct & Global Distribution

Hydraulic Valves P40-U34-2OT | Factory Direct & Global Distribution drawing image

The P40-U34-2OT is a high-performance electromagnetic hydraulic valve designed for demanding applications in material handling, construction, and industrial vehicles. This 2-section monoblock valve boasts a rated flow of 40 L/min and a maximum pressure of 250 bar, ensuring reliable operation in a wide range of environments.

Serie P40 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 40 l/min (10,5 gal EE. UU./min)
Presión Máxima 250 bar (3600 psi)
Puerto de Entrada G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Puerto de Salida G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT
Tamaño de Puerto G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT

The P40-U34-2OT is a robust and reliable electromagnetic hydraulic valve specifically engineered for heavy-duty applications. It features a compact monoblock design with a 2-section configuration, offering efficient control and high flow capacity. This valve is capable of handling a rated flow of 40 L/min (10.5 US gpm) at a maximum pressure of 250 bar (3600 psi), making it suitable for demanding applications. Its wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) and ambient temperature range of -40°C to +80°C (-40°F to +176°F) ensure reliable performance in various operating conditions. The P40-U34-2OT is specifically designed for applications in material handling, construction, and industrial vehicles, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, and wheel loaders. Its high performance and durability make it an ideal choice for manufacturers and end-users looking for reliable and efficient hydraulic control solutions.
