Hydraulic Valve P80J: Factory Direct & Global Distribution

Método de control:Manual

Carrete:1 carrete

Flujo Nominal:80 l/min (21,2 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:1/2 NPT

Puerto de Salida:1/2 NPT

Tamaño de Puerto:1/2 NPT

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P80J Válvula Direccional Monobloque

Tamaño del embalaje:26*15*11

Peso bruto:5.00 kg

Disponibilidad: En stock

1083 personas están viendo este producto

Hydraulic Valve P80J: Factory Direct & Global Distribution

Hydraulic Valve P80J: Factory Direct & Global Distribution

Hydraulic Valve P80J: Factory Direct & Global Distribution drawing image

The P80J Hydraulic Control Valve is a high-performance, manual control valve designed for log splitters and a variety of construction and material handling equipment. With a rated flow of 80 L/min and a maximum pressure of 250 bar, this monoblock valve is built to withstand demanding applications. It is available for global distribution directly from the factory.

Serie P80J Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Eléctrico, 在这里输入键名的翻译, Solenoide y joystick, Manual y joystick
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 80 l/min (21,2 gal EE. UU./min)
Presión Máxima 315 bar (4600 psi)
Puerto de Entrada G1/2, G3/4, M20×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Puerto de Salida G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamaño de Puerto G1/2, G3/4, M20×1.5, M22×1.5, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT

The P80J Hydraulic Control Valve is a robust and reliable solution for controlling hydraulic systems in a variety of applications. Its monoblock construction ensures durability and long-lasting performance. With a rated flow of 80 L/min and a maximum pressure of 250 bar, it is suitable for heavy-duty log splitting and other applications requiring high flow and pressure. The manual control method provides simple and straightforward operation. This valve is specifically designed for use in various equipment including telehandlers, forklifts, all terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. The P80J series is manufactured to the highest quality standards and is available for global distribution directly from the factory, ensuring a reliable and cost-effective solution for your hydraulic needs.
