High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

Método de control:Manual

Carrete:4 carretes

Flujo Nominal:80 l/min (21,2 gal EE. UU./min)

Presión Máxima:250 bar (3600 psi)

Puerto de Entrada:G1/2

Puerto de Salida:G3/4

Tamaño de Puerto:G1/2

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie P80 Válvula Direccional Monobloque

Tamaño del embalaje:26*27*11

Peso bruto:13.40 kg

Disponibilidad: En stock

1412 personas están viendo este producto

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems

High-Quality P80-G34-G12-AT-3OT Directional Valve for Hydraulic Systems drawing image

The P80-G34-G12-AT-3OT is a high-quality 4-section monoblock directional valve designed for hydraulic systems. It features a joystick control method, a rated flow of 80 L/min (21.2 US gpm), and a maximum pressure of 250 bar (3600 psi). This versatile valve is suitable for various applications, including material handling, construction, agriculture, and industrial vehicles.

Serie P80 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Manual y joystick
Carrete 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes
Rango de temperatura ambiente -40 °C a +80 °C (-40 °F a +176 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 80 l/min (21,2 gal EE. UU./min)
Presión Máxima 315 bar (4600 psi)
Puerto de Entrada G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Puerto de Salida G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT
Tamaño de Puerto G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT

The P80-G34-G12-AT-3OT joystick hydraulic valve is a robust and reliable solution for demanding hydraulic systems. Its 4-section monoblock construction ensures high performance and durability. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure rating of 250 bar (3600 psi), this valve is capable of handling heavy-duty applications. The valve is designed to operate within an ambient temperature range of -40°C to +80°C (-40°F to +176°F) and a viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt). Its 4-spool configuration provides precise control over hydraulic functions. The P80-G34-G12-AT-3OT is ideal for a wide range of applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, and skid steer loaders. Its high-quality construction, robust performance, and versatility make it an excellent choice for manufacturers and users in various industries.
