Introducing our Bespoke Hydraulic Solutions: P80-G12-G34-OW Directional Control Valves, meticulously designed and manufactured to meet your unique hydraulic system requirements. These high-performance valves are customizable to fit your specific application, ensuring optimal control and efficiency.
| Serie P80 Válvula Direccional Monobloque Parámetros | |
|---|---|
| Método de control | Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Manual y joystick |
| Carrete | 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes |
| Rango de temperatura ambiente | -40 °C a +80 °C (-40 °F a +176 °F) |
| Tipo de estructura | Válvulas monobloc |
| Sección | 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones |
| Rango de viscosidad de funcionamiento | 15 - 75 mm²/s (15 cSt a 75 cSt) |
| Flujo Nominal | 80 l/min (21,2 gal EE. UU./min) |
| Presión Máxima | 315 bar (4600 psi) |
| Puerto de Entrada | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Puerto de Salida | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Tamaño de Puerto | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
**P80 Series Customizable Directional Control Valves**
**Key Features:**
- Manual control for precise operation
- Monoblock valve construction for durability and compactness
- Rated flow of 80 L/min (21.2 US gpm) for efficient hydraulic fluid flow
- Maximum pressure of 250 bar (3600 psi) for demanding applications
- Operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt) for versatility
- Ambient temperature range of -40°C to +80°C (-40°F to +176°F) for wide-ranging operation
**Applications:**
- Material Handling: Telehandlers, Forklifts
- Construction and Earth Moving: All Terrain Cranes, Stackers, Motor Graders
- Agriculture: Tractors, Harvesters
- Industrial Vehicles: Aerial Platforms, Skid Steer Loaders
Our P80 Series Directional Control Valves are meticulously engineered to provide exceptional performance and reliability, making them the ideal choice for a wide array of mobile hydraulic applications.
