1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

Método de control:Manual

Carrete:1 carrete

Flujo Nominal:120 L/min (31.7 US gpm)

Presión Máxima:305 bar (4400 psi)

Puerto de Entrada:G3/4

Puerto de Salida:G3/4

Tamaño de Puerto:G3/4

Marca:BXHS

Tipo de producto:Válvula Direccional Monobloque

Serie de productos:Serie SD14 Válvula Direccional Monobloque

Tamaño del embalaje:15*26*15

Peso bruto:6.80 kg

Disponibilidad: En stock

1085 personas están viendo este producto

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable

1-Spool Hydraulic Valve | SD14 Model | Factory Direct & Customizable drawing image

The SD14 Series Hydraulic Sectional Valve is a high-performance, 1-spool monoblock valve designed for demanding applications in material handling, construction, agriculture, and industrial vehicles. Featuring manual control and a rated flow of 120 L/min (31.7 US gpm), this valve is ideal for telehandlers, forklifts, excavators, loaders, and other mobile equipment.

Serie SD14 Válvula Direccional Monobloque Parámetros
Método de control Manual, Neumático, Hidráulico
Carrete 1 carrete
Rango de temperatura ambiente -40 °C a +60 °C (-40 °F a +140 °F)
Tipo de estructura Válvulas monobloc
Sección 1 sección
Rango de viscosidad de funcionamiento 15 - 75 mm²/s (15 cSt a 75 cSt)
Flujo Nominal 120 L/min (31.7 US gpm)
Presión Máxima 315 bar (4600 psi)
Puerto de Entrada G3/4
Puerto de Salida G3/4
Tamaño de Puerto G3/4

This SD14 Series Hydraulic Sectional Valve is a robust, reliable, and customizable solution for your hydraulic system needs. It features a monoblock construction for increased strength and durability. With a rated flow of 120 L/min (31.7 US gpm) and a maximum pressure of 315 bar (4600 psi), this valve delivers the power and performance you need for demanding applications. This valve is designed for a wide range of operating temperatures (-40°C to +60°C) and viscosities (15 - 75 mm²/s), ensuring reliable operation in various environments. Available directly from our factory, you can customize this valve to meet your specific requirements. Our SD14 Series Hydraulic Sectional Valve is suitable for a wide range of applications, including: Telehandlers, Forklifts, All Terrain Cranes, Stackers, Aerial Platforms, Motor Graders, Midi-Excavators, Mini-Excavators, Skid Steer Loaders, and Compact Wheel Loaders. Contact us today to discuss your specific needs and get a customized solution.
