This Electro Pneumatic Control 1-Spool Hydraulic Directional Valve is a reliable and efficient solution for controlling hydraulic systems in various applications, including material handling, construction, agriculture, and industrial vehicles. It features manual control, a monoblock valve structure, and a rated flow of 40 L/min. The valve is customizable and available directly from the factory.
| Serie P40 Válvula Direccional Monobloque Parámetros | |
|---|---|
| Método de control | Manual, Neumático, Electoneumático, Electrohidráulico, Solenoide, Hidráulico, Hidráulico y Manual, Cable, Joystick, Solenoide y joystick, Manual y joystick, Solenoide y cable |
| Carrete | 1 carrete, 2 carretes, 3 carretes, 4 carretes, 5 carretes, 6 carretes, 7 carretes |
| Rango de temperatura ambiente | -40 °C a +80 °C (-40 °F a +176 °F) |
| Tipo de estructura | Válvulas monobloc |
| Sección | 1 sección, 2 secciones, 3 secciones, 4 secciones, 5 secciones, 6 secciones, 7 secciones |
| Rango de viscosidad de funcionamiento | 15 - 75 mm²/s (15 cSt a 75 cSt) |
| Flujo Nominal | 40 l/min (10,5 gal EE. UU./min) |
| Presión Máxima | 250 bar (3600 psi) |
| Puerto de Entrada | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Puerto de Salida | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Tamaño de Puerto | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
The P40 Series Electro Pneumatic Control 1-Spool Hydraulic Directional Valve is a high-performance valve designed for demanding applications. It offers a compact and robust design, with a single spool and a rated flow of 40 L/min. The valve can withstand a maximum pressure of 250 bar and operates within a viscosity range of 15 - 75 mm²/s. It features manual control for precise operation. The valve is suitable for a wide range of applications, including telehandlers, forklifts, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, tractors, and front-end loaders. Its versatility and reliability make it an ideal choice for various industries. The valve is available directly from the factory and can be customized to meet specific requirements.
